Single-Sideband Mixers –
Coaxial SSB mixers (TalentMW). Image rejection specified at 25 dBc for the listed bands. SMA interface.
Single-Sideband Mixer (SSB)
RF/LO: 4–20 GHz class
IF: 0.1 GHz or 3–4 GHz
Image Rejection: 25 dBc
Connector: SMA
Selection notes
Select by RF/LO band and required IF. Confirm conversion loss, LO drive and flatness on the datasheet for the exact part number.
- IF options shown: 0.1 GHz or 3–4 GHz
- Image rejection shown: 25 dBc (verify conditions in datasheet)
Models list (Single-Sideband Mixer)
| Model | RF (GHz) | LO (GHz) | IF (GHz) | Image Rejection (dBc) | RF Connectors | Datasheet |
|---|---|---|---|---|---|---|
| TLSSBM-4G8G-0.1G-S | 4–8 | 4–8 | 0.1 | 25 | SMA | Datasheet |
| TLSSBM-6G26G-3G4G-S | 6–26 | 6–26 | 3–4 | 25 | SMA | Datasheet |
| TLSSBM-8G12.5G-0.1G-S | 8–12.5 | 8–12.5 | 0.1 | 25 | SMA | Datasheet |
| TLSSBM-12.5G20G-0.1G-S | 12.5–20 | 12.5–20 | 0.1 | 25 | SMA | Datasheet |
Source list: TalentMW “Single-Sideband Mixer” product table (cid3=190). Verify full specs on the datasheet for the exact PN.
