Pin Diode Switch SP6T
|
Part Number |
Frequency (GHz) |
Insert. Loss (dB) |
Isolation (dB) |
Avg. Power (W) |
Switching Speed (ns) |
Style |
|
RFSP6TA0002M |
0.001 ~ 0.2 |
1.6 |
70 |
1~5 |
250 |
Absorptive |
|
RFSP6TA0005M |
0.02 ~ 0.5 |
1.7 |
80 |
1~5 |
250 |
Absorptive |
|
RFSP6TA0001G |
0.02 ~ 1 |
1.7 |
70 |
1~5 |
250 |
Absorptive |
|
RFSP6TA0501G |
0.5 ~ 1 |
1.8 |
80 |
1~5 |
200 |
Absorptive |
|
RFSP6TA0102G |
1 ~ 2 |
1.6 |
80 |
1~5 |
50 |
Absorptive |
|
RFSP6TA0003G |
0.02 ~ 3 |
2.8 |
60 |
1~5 |
250 |
Absorptive |
|
RFSP6TA5M04G |
0.5 ~ 4 |
2.0 |
60 |
1~5 |
200 |
Absorptive |
|
RFSP6TA0204G |
2 ~ 4 |
2.0 |
80 |
1~5 |
50 |
Absorptive |
|
RFSP6TA0208G |
2 ~ 8 |
2.4 |
60 |
1~5 |
50 |
Absorptive |
|
RFSP6TA0612G |
6 ~ 12 |
3.0 |
60 |
1~5 |
50 |
Absorptive |
|
RFSP6TA0018G |
0.02 ~ 18 |
2.0 |
60 |
1 |
250 |
Absorptive |
|
RFSP6TA0118G |
1 ~ 18 |
3.8 |
60 |
1 |
50 |
Absorptive |
|
RFSP6TA0218B |
2 ~ 18 |
4.1 |
60 |
1~5 |
50 |
Absorptive |
|
RFSP6TA0618G |
6 ~ 18 |
3.8 |
60 |
1~5 |
50 |
Absorptive |
|
RFSP6TA0220G |
2 ~ 20 |
4.1 |
60 |
0.2~1.0 |
50 |
Absorptive |
|
RFSP6TA5M43G |
0.5 ~ 43.5 |
7.0 |
60 |
0.1 |
200 |
Absorptive |
|
RFSP6TA5M50G |
0.05 ~ 50 |
7.0 |
60 |
0.1 |
100 |
Absorptive |
|
Part Number |
Frequency (GHz) |
Insert. Loss (dB) |
Isolation (dB) |
Avg. Power (W) |
Switching Speed (ns) |
Style |
|
RFSP6TR0002M |
0.001 ~ 0.2 |
1.5 |
70 |
1~200 |
1000 |
Reflective |
|
RFSP6TR0005M |
0.02 ~ 0.5 |
1.6 |
80 |
1~200 |
500 |
Reflective |
|
RFSP6TR0001G |
0.02 ~ 1 |
1.6 |
70 |
1~100 |
500 |
Reflective |
|
RFSP6TR0501G |
0.5 ~ 1 |
1.7 |
80 |
1~200 |
200 |
Reflective |
|
RFSP6TR0102G |
1 ~ 2 |
1.4 |
80 |
1~200 |
100 |
Reflective |
|
RFSP6TR0003G |
0.02 ~ 3 |
2.6 |
60 |
1~100 |
500 |
Reflective |
|
RFSP6TR0004G |
0.5 ~ 4 |
2.0 |
60 |
1~100 |
200 |
Reflective |
|
RFSP6TR0204G |
2 ~ 4 |
1.6 |
80 |
1~100 |
100 |
Reflective |
|
RFSP6TR0208G |
2 ~ 8 |
2.4 |
60 |
1~50 |
100 |
Reflective |
|
RFSP6TR0612G |
6 ~ 12 |
3.0 |
60 |
1~30 |
100 |
Reflective |
|
RFSP6TR0018G |
0.02 ~ 18 |
2.0 |
60 |
1 |
250 |
Reflective |
|
RFSP6TR0218G |
2 ~ 18 |
3.2 |
80 |
1~10 |
100 |
Reflective |
|
RFSP6TR0618G |
6 ~ 18 |
3.5 |
60 |
1~10 |
100 |
Reflective |
|
RFSP6TR0220G |
2 ~ 20 |
3.2 |
80 |
0.5~5.0 |
100 |
Reflective |
